SSRF
What is an SSRF?
Room Brief
In this room, you'll learn what an SSRF is, what kind of impact they can have, you'll view some example SSRF attacks, how you can discover SSRF vulnerabilities, how to circumvent input rules and then we have a practice for you against with to try your newfound skills.
What is an SSRF?
SSRF stands for Server-Side Request Forgery. It's a vulnerability that allows a malicious user to cause the webserver to make an additional or edited HTTP request to the resource of the attacker's choosing.
Types of SSRF
There are two types of SSRF vulnerability; the first is a regular SSRF where data is returned to the attacker's screen. The second is a Blind SSRF vulnerability where an SSRF occurs, but no information is returned to the attacker's screen. What's the impact?
A successful SSRF attack can result in any of the following:
What does SSRF stand for? Server-Side Request Forgery.
As opposed to a regular SSRF, what is the other type? Blind
SSRF Examples
Click the View Site button, which will take you through some common SSRF examples, how to exploit them and even a simulation to see if you can take advantage of an SSRF vulnerability using what you've learnt.
Instructions The below example shows how the attacker can have complete control over the page requested by the webserver. The Expected Request is what the website.thm server is expecting to receive, with the section in red being the URL that the website will fetch for the information. The attacker can modify the area in red to an URL of their choice.
The below example shows how an attacker can still reach the /api/user page with only having control over the path by utilising directory traversal. When website.thm receives ../ this is a message to move up a directory which removes the /stock portion of the request and turns the final request into /api/user
In this example, the attacker can control the server's subdomain to which the request is made. Take note of the payload ending in &x= being used to stop the remaining path from being appended to the end of the attacker's URL and instead turns it into a parameter (?x=) on the query string.
Going back to the original request, the attacker can instead force the webserver to request a server of the attacker's choice. By doing so, we can capture request headers that are sent to the attacker's specified domain. These headers could contain authentication credentials or API keys sent by website.thm (that would normally authenticate to api.website.thm).
Using what you've learnt, try changing the address in the browser below to force the webserver to return data from https://server.website.thm/flag?id=9. To make things easier the Server Requesting bar at the bottom of the mock browser will show the URL that website.thm is requesting.
Question Hint Append &x= at the end to ignore the rest of the URL.
By including the “&x=” payload at the end of the URL, you can bypass it.
It works because it prevents the attacker’s remaining default “URL Path” from being attached to the end of the attacker’s URL.
What is the flag from the SSRF Examples site? THM{SSRF_MASTER}
Finding an SSRF
Potential SSRF vulnerabilities can be spotted in web applications in many different ways. Here is an example of four common places to look:
A partial URL such as just the hostname:
Or perhaps only the path of the URL:
Some of these examples are easier to exploit than others, and this is where a lot of trial and error will be required to find a working payload.
If working with a blind SSRF where no output is reflected back to you, you'll need to use an external HTTP logging tool to monitor requests such as requestbin.com, your own HTTP server or Burp Suite's Collaborator client.
What website can be used to catch HTTP requests from a server? requestbin.com
Defeating Common SSRF Defenses
More security-savvy developers aware of the risks of SSRF vulnerabilities may implement checks in their applications to make sure the requested resource meets specific rules. There are usually two approaches to this, either a deny list or an allow list.
Deny List
A Deny List is where all requests are accepted apart from resources specified in a list or matching a particular pattern. A Web Application may employ a deny list to protect sensitive endpoints, IP addresses or domains from being accessed by the public while still allowing access to other locations. A specific endpoint to restrict access is the localhost, which may contain server performance data or further sensitive information, so domain names such as localhost and 127.0.0.1 would appear on a deny list. Attackers can bypass a Deny List by using alternative localhost references such as 0, 0.0.0.0, 0000, 127.1, 127...*, 2130706433, 017700000001 or subdomains that have a DNS record which resolves to the IP Address 127.0.0.1 such as 127.0.0.1.nip.io.
Also, in a cloud environment, it would be beneficial to block access to the IP address 169.254.169.254, which contains metadata for the deployed cloud server, including possibly sensitive information. An attacker can bypass this by registering a subdomain on their own domain with a DNS record that points to the IP Address 169.254.169.254.
Allow List
An allow list is where all requests get denied unless they appear on a list or match a particular pattern, such as a rule that an URL used in a parameter must begin with https://website.thm. An attacker could quickly circumvent this rule by creating a subdomain on an attacker's domain name, such as https://website.thm.attackers-domain.thm. The application logic would now allow this input and let an attacker control the internal HTTP request.
Open Redirect
If the above bypasses do not work, there is one more trick up the attacker's sleeve, the open redirect. An open redirect is an endpoint on the server where the website visitor gets automatically redirected to another website address. Take, for example, the link https://website.thm/link?url=https://tryhackme.com. This endpoint was created to record the number of times visitors have clicked on this link for advertising/marketing purposes. But imagine there was a potential SSRF vulnerability with stringent rules which only allowed URLs beginning with https://website.thm/. An attacker could utilise the above feature to redirect the internal HTTP request to a domain of the attacker's choice.
What method can be used to bypass strict rules? Open Redirect
What IP address may contain sensitive data in a cloud environment? 169.254.169.254
What type of list is used to permit only certain input? allow list
What type of list is used to stop certain input? deny list
SSRF Practical
Let's put what we've learnt about SSRF to the test in a fictional scenario.
We've come across two new endpoints during a content discovery exercise against the Acme IT Support website. The first one is /private, which gives us an error message explaining that the contents cannot be viewed from our IP address. The second is a new version of the customer account page at /customers/new-account-page with a new feature allowing customers to choose an avatar for their account.
Begin by clicking the Start Machine button to launch the Acme IT Support website. Once running, visit it at the URL https://10-10-109-81.p.thmlabs.com and then follow the below instructions to get the flag.
First, create a customer account and sign in. Once you've signed in, visit https://10-10-109-81.p.thmlabs.com/customers/new-account-page to view the new avatar selection feature. By viewing the page source of the avatar form, you'll see the avatar form field value contains the path to the image. The background-image style can confirm this in the above DIV element as per the screenshot below:
If you choose one of the avatars and then click the Update Avatar button, you'll see the form change and, above it, display your currently selected avatar. Viewing the page source will show your current avatar is displayed using the data URI scheme, and the image content is base64 encoded as per the screenshot below.
Now let's try making the request again but changing the avatar value to private in hopes that the server will access the resource and get past the IP address block. To do this, firstly, right-click on one of the radio buttons on the avatar form and select Inspect:
And then edit the value of the radio button to private:
And then click the Update Avatar button. Unfortunately, it looks like the web application has a deny list in place and has blocked access to the /private endpoint.
As you can see from the error message, the path cannot start with /private but don't worry, we've still got a trick up our sleeve to bypass this rule. We can use a directory traversal trick to reach our desired endpoint. Try setting the avatar value to x/../private
You'll see we have now bypassed the rule, and the user updated the avatar. This trick works because when the web server receives the request for x/../private, it knows that the ../ string means to move up a directory that now translates the request to just /private.
Viewing the page source of the avatar form, you'll see the currently set avatar now contains the contents from the /private directory in base64 encoding, decode this content and it will reveal a flag that you can enter below.
VEhNe1lPVV9XT1JLRURfT1VUX1RIRV9TU1JGfQ==
What is the flag from the /private directory? THM{YOU_WORKED_OUT_THE_SSRF}
